Walkie talkie Baofeng bf uv82 Dualband
RM 68.00
Product Description
BaoFeng Newest Handheld Walkie Talkie UV-82 Dual Band 136-174MHz&400-520MHz with Double PTT Button New Design
Notice:
*This Radio is the Newest Dual Band Radio of BaoFeng Radio Factory
*Same Frequency range as UV-5R 136-174MHz&400-520Mhz.
*New design in appearance,offer a better feeling when holding in hands.
*Charger Apaptor is the same as UV-5R,easy to find replacement parts.
*Have strong flashlight and Double PTT button in TX/RX
Features:
- Frequency Range: 136-174 & 400-520MHz
- Double PTT Design
- Dual Band, Dual Display, Dual Frequency,Dual Standby
- Dual band, dual display
- A/B band independent operation
- 128 groups channels storage
- Shortcut menu operation mode
- VFO & Memory channels scan
- Emergency Alarm
- Tri-color background light selectable
- 0~9 grades VOX selectable
- PTT & ANI ID
- FM radio and 25 stations storage
- 1750Hz Brust
- Tone Time-out Timer
- Channel Monitor
- Battery Saver
- Keypad Lock
- Channel Step: 2.5/5/6.25/10/12.5/25KHz
- Low Battery Alert
- ROGER SET
- Emergency Alert
- 25KHz/12.5KHz Switchable
- FM Radio (65.0MHz-108.0MHz)
- Large LCD Display
- LED Flashlight
- Hight /Low RF Power Switchable
- Voice companding
- 50 CTCSS/ 104DCS coder & tone searching
- dual standby
- PC programmable
- Wide/Narrow Band(25kHz/12.5kHz)
- Transmitter time-out timer(TOT)
- High/Low TX power selectable
- Busy channel lock-out(BCLO)
Specifications:
General | |
Frequency Range | 65-108MHz(FM Receive only) |
136-174MHZ and 400-520MHZ (TX/RX) | |
Channel No. | 128 |
Frequency Stability | ±2.5ppm |
Antenna | High gain DualBand antenna |
Antenna Impedance | 50Ω |
Operating Voltage | DC 7.4V |
Mode of operation | Simple or semi-duplex |
Antenna : | SMA -Female |
Earpiece / mic type : | Kenwood Plug type |
Dimension(W x H x D) | 130 x 60 x 35 mm (not included antenna) |
Weight | 238g(including battery, antenna) |
Power adapter | Input: AC100-240V, 50-60Hz; Output: DC10V/500mA; Plug Type: European/US Plug and AU/UK/Japan Adaptors Available |
Transmitter | |
Output power | 5W / 1W (Max 5W) |
Modulation Mode | 16kΦF3E / 11kΦF3E |
Maximum deviation | 5kHz(Wide) / 2.5kHz(Narrow) |
Spurious Radiation | 7μW |
Adjacent Ch. power | ≤-65dB(Wide) / ≤-60dB(Narrow) |
Pre-emphasis characteristics | 6dB |
Current | ≤1.6A(5W) |
CTCSS/DCS deviation | 0.5±0.1kHz(Wide) / 0.3±0.1kHz(Narrow) |
Intermediation sensitivity | 8-12mv |
Intermediation distortion | ≤10% |
